Product

Pressure switch

Type

HP87

Application

It can be used in home boiler, water purifier, washer, etc.

A SPDT switch, which is used to control the pressure.

Material

Body: nylon 66

Gas body: bronze (5-5-5 tin bronze)

Film: silicon rubber

Micro switch is made use of famous switch (CHERRY)

Electrical parameter

15A，1/2HP，125VAC~250VAC

Working temperature

-40℃~125℃

Environment temperature

-40℃~85℃

Range of pressure

0.001 bar~0.2 bar

Max.working pressure

2 bar

Connector

G1/4，G1.8，M12×1.25
